                                              ALL RJ45'S  ARE NOT  CREATED EQUAL

Thanks for stopping by our web site and we appreciate your interest. Our goal is to inform, educate, increase the awareness level and explain some of the PROBLEM AREAS associated with the RJ-45 interface. By doing so, customers will hopefully make better product selections and get the desired results they are seeking. Please take a few minutes to navigate our site and we hope you find this information helpful.

The RJ-45 Is A Highly Engineered Interconnection System

SUB-STANDARD, NON-COMPLIANT and COUNTERFEIT RJ45's coming in from the Far East

      KNOW THE STANDARDS - KNOW THE SPECS - INSIST ON COMPLIANCE - KNOW YOUR SUPPLIERS




      "Moving at the Speed of Right"



RJ45 AUTHORITATIVE EXPERTS WITH OVER 35 PATENTS
Why Not Go To The Best In The First Place?


Sentinel Connector Systems is the premier "MADE IN USA" manufacturer of RJ-45 Plugs and Jacks. As a matter of fact, Bob Brennan, Founder and President of Sentinel Connector (former Founder/President of Stewart Connector) has been involved with RJ45s since their inception. Bob was part of the team that built the first RJ45 back in the 1970's consulting with Hardesty and Gustin who worked at Western Electric creating the FCC Part 68 Specification (superseded by ANSI/TIA-1096-A). Bob and the Sentinel East Team have over 35  foreign and domestic patents relating to the RJ45 Interconnect. Significant Patents include the MagJack, a Proprietary Gold Plating Process called Spot Plating and a Composite Carbon/Graphite Fiber Conductive Load Bar.

In addition, we have the BOOK OF RJ.....representing over 40 years of hand written notes about the why's, do's and dont's of manufacturing RJ-45 Interconnection Systems


THE SENTINEL CONNECTOR SYSTEMS ADVANTAGE


THE BOOK OF RJ (Robert J Brennan)



WE DO EVERYTHING FOR A REASON

ALL PRODUCTS MEET/EXCEED THE FOLLOWING STANDARDS
 ANSI/TIA/EIA 568 - ANSI/TIA 1096-A (Formerly FCC Part 68)
CENELEC EN 50173 - IEC 60603 - ISO-8877 - ISO/IEC 11801



THE SENTINEL CONNECTOR SYSTEMS ADVANTAGE - All of Sentinel's Plugs and Jacks are built in accordance to INDUSTRY STANDARDS & SPECIFICATIONS as set forth by governing bodies such as ACTA, ASTM, FCC, IEC, IEEE, ISO, TIA and UL.  Sentinel is also a Member of the Communications Cable and Connectivity Association.....adhering to the Association's STRICT CODE OF ETHICS regarding compliance.


HOW WE BUILD THINGS


The BASIS METAL for the contacts is PHOSPHOR BRONZE. We use a very specific % along with a very tightly controlled min-max granular MICROSTRUCTURE to provide the best STIFFNESS, SPRING QUALITIES and CORROSION & WEAR RESISTANCE. The base metal is ELECTRO-POLISHED (versus wire brushed) creating an extremely smooth "BURR FREE" CONTACT SURFACE. It is then plated with 100 micro inches of pure Nickel (min plugs, 50 micro min jacks)....providing a sacrificial metal surface/barrier to PROHIBIT DIFFUSION and OBTAIN THE DESIRED POROSITY CHARACTERISTICS....then 50 micro inches (minimum) of pure 24 CARAT (hard) GOLD adhering to MIL-G-45204C, TYPE II, GRADE A specifications and Knoop Hardness requirements. During each plating operation, PROPER SURFACE ACTIVATION and CLEANSING PROCEDURES are meticulously followed to insure against any possible surface contamination and potential GALVANIC REACTIONS (reference MIL-STD-889).


By incorporating the strict design guidelines above, Sentinel Plugs and Jacks will have a MINIMUM 1,000 CYCLE LIFE (insertions/de-insertions) before any degradation of surface contact areas and a 2,000 MINIMUM CYCLE LIFE WHEN USING SENTINEL PLUG/JACK COMBINATIONS.


THE BOTTOM LINE - WE DO NOT CUT CORNERS.....WE USE BEST PRACTICES.....WE MEET and/or EXCEED ALL STANDARDS....WE PROVIDE THE HIGHEST QUALITY IN THE MARKETPLACE.....and best yet, WE ARE EASY TO WORK WITH and our products are MADE IN THE UNITED STATES OF AMERICA.


______________________


WE ENCOURAGE YOU TO
"KNOW YOUR SUPPLIERS"


Somewhere along the line, either through COST PRESSURES, OUTSOURCING, MATERIAL SELECTION, PRODUCT DESIGN, or a host of other reasons, some RJ45 modular connector manufacturers have strayed from the specifications as set forth by the Standards Bodies (such as ACTA, ASTM, EIA, FCC, IEC, IEEE, ISO, TIA and UL). As a result, there is a growing problem in the field relating to POROSITY, OXIDATION, CORROSION, CONDUCTIVITY, CONTACT RESISTANCE, INTERMITTENCIES AND LOSS OF SIGNAL that have become more pervasive recently. For example.......

OVER 50% of all RJ-45 Plugs tested DID NOT MEET THE MINIMUM GOLD and/or NICKEL PLATING REQUIREMENTS PER TIA, IEC AND FCC SPECIFICATIONS

The Telecommunications Industry Association (TIA) has reported that (RJ-45 plug/jack) "connectors continue to be a source of problems for customers. For example, connectors are reaching the marketplace without the requisite amount of gold on the connector contacts." In particular, "such plugs and jacks may be difficult to interconnect and may lack the gold plating on the contact interface needed to prevent interference." To learn more, go to.....

GOLD and NICKEL Plating Issues

THERE IS A DISTURBING TREND OF RJ45 PLUGS AND JACKS
NOT MEETING DIMENSIONAL SPECIFICATIONS PUT FORTH BY THE TIA, IEC, ISO AND FCC

CAUSING PERFORMANCE ISSUES and POTENTIAL LOSS OF SIGNAL



Proper design elements (TOOLING DESIGN, MOLD DRAFTS, TOLERANCES) based on Standards and Specifications are not being adhered to. This has affected the Plug/Jack MATING CHARACTERISTICS and their relationship to TARGETING and GUIDANCE. In addition, SURFACE CONTACT MATING AREAS are Affecting Signal Quality.....Resulting in Poor Signal Transmission, Intermittencies, Shorts and Potential Signal Loss. To learn more, go here.....

RJ45 Plug, Jack and Contact Design

RJ45 Plug and Jack Mating


85% OF ALL CATEGORY 6 PATCH CABLES FAIL ELECTRICAL TESTING
and 78% FAIL BY 3db OR MORE and 45% FAIL BY 6db OR MORE

A recent study conducted by the Communications Cable and Connectivity Association (CCCA) found that 85% of all Category 6 patch cables FAILED ELECTRICAL TESTING! This reinforces a 2008 study by Fluke Network Systems showing that 83% OF CATEGORY 6 COPPER PATCH CORDS FAILED to meet the TIA specification requirements. To learn more, go to:

______________________


THE BOTTOM LINE

KNOW THE STANDARDS

KNOW THE SPECIFICATIONS

INSIST ON COMPLIANCE

KNOW YOUR SUPPLIERS
